Key Applications:
The P1.53 GOB Indoor LED Module is ideal for environments that demand high-resolution visuals and reliable performance, such as control rooms, broadcast studios, corporate lobbies, conference centers, exhibition venues, and luxury retail displays.
Brand :
HoozoeModel :
P1.53 GOB LED Display Screen ModuleOrder(MOQ) :
40 pcsPayment :
TTProduct Origin :
ChinaColor :
BlackShipping Port :
XiamenLead Time :
7 daysWeight :
0.5kgFeatures
Pixel Pitch:
1.53 mm pixel pitch delivers sharp, grain-free visuals at close to medium viewing distances.
High Resolution & Detail:
GOB encapsulation enhances protection and viewing consistency, supporting vivid HD content even in bright indoor lighting.
Optimal Viewing Distance:
Designed for clear viewing within 1.5–10 meters, ensuring a seamless experience without visible pixelation.
Reliable Technology:
GOB coating protects against dust, impact, and environmental wear, improving durability while maintaining thermal and optical performance.
Easy Installation & Maintenance:
Standard modular size allows quick assembly and front maintenance, with factory calibration ensuring consistent color and brightness.
Typical Applications:
Ideal for control rooms, studios, corporate lobbies, conference halls, exhibitions, and luxury retail.
Parameter
| Parameter Name | Product Parameter | |
| Screen | Maximum power consumption | 510 W/㎡ |
|
Usage environment |
Indoor | |
|
Viewing distance |
≥2.0m | |
|
Blind spot rate |
Less than 0.02% | |
| Brightness | > 600 cd/㎡ | |
| Average power consumption of the screen | 180-250 W/㎡ | |
| Horizontal viewing angle of screen | 140±10 degree | |
|
Vertical viewing angle of the screen |
140±10 degree | |
| Module |
Pixel Pitch |
1.53 mm |
|
Pixel Density |
422533 Dots/㎡ | |
| Resolution | 208x104=21632 Dots | |
| Structural characteristics | Integrated light drive system | |
| Pixel composition | 1R1G1B | |
| Drive mode | 1/52 scan constant current drive | |
| Input voltage | 4.2-5 V | |
|
Kit materials |
Polycarbonate PC material | |
| Weight | 450 g | |
| Power of unit module | <26 W | |
| Size (Long, Wide, and Thick) | 320*160*14.5(mm) | |
| Maximum current | <5.2 A | |
|
Use 4.2V/5V Switching Power Supply with Load Quantity |
<6 pieces P1.53 full-color unit boards | |
|
System |
Frame Frequency |
>60 frames per second |
|
Refresh frequency |
≥3840Hz |
|
|
Control mode |
Computer control, one-to-one correspondence point by point, video synchronization, real-time display |
|
|
Brightness adjustment |
256 level manual/automatic |
|
| Driver chip mode |
Buffer 74HC245, Row Tube 9736, PWM Constant Current IC |
|
Certetifcation of Hoozoe GOB LED Display Modules

Core Advantages of Hoozoe GOB LED Display Modules
1. Superior Image Quality
Fine pixel pitch (e.g., P1.25–P2.5) ensures sharp, detailed visuals even at close viewing distances
High color saturation delivers vivid and true-to-life imagery
Adaptive brightness and contrast ratio for comfortable viewing in ambient light
2. Seamless Tiling & Flexible Expansion
Modular design allows assembly into large screens of any size and aspect ratio
Supports curved, column, and other custom shapes for diverse spatial layouts
3. Reliability & Energy Efficiency
Capable of 24/7 continuous operation with a lifespan of 100,000+ hours
GOB encapsulation provides dust and impact resistance for demanding indoor environments
Low power consumption and minimal heat generation for quiet, efficient operation
4. Dynamic Content & Interactive Capability
Supports video, animations, real-time data, and other dynamic content formats
Enables integration with touch and sensor technologies for interactive experiences
5. Professional & Commercial Value
Elevates corporate image with modern, high-impact visual communication
Ideal for information delivery in control rooms, lobbies, retail, and public spaces
Increases engagement and conversion rates in commercial environments
